Gent S3-S-VAD-LPR Sounder with Standard Power VAD | Red body – Red lens

Gent S3-S-VAD-LPR Power Sounder with Red VAD – Red Body

The Gent S3-S-VAD-LPR is a loop-powered alarm sounder designed for use with Gent Vigilon fire alarm systems. Featuring a red body and a red EN54-23-certified Visual Alarm Device (VAD), this device provides both audible and visual warning signals, ensuring rapid and effective occupant notification during a fire emergency.

As part of the S-Cubed range, the Gent S3-S-VAD-LPR integrates voice messaging, tone alerts, and synchronised visual alarms in one compact device. The low-current design allows the Vigilon system to support a greater number of sounders and VADs per loop than competing systems, which in turn reduces installation costs and maximises coverage.

The S3 Standard Power variant of the Gent S3-S-VAD-LPR is ideal for applications that require a balance between performance and power efficiency. It supports multiple operating modes, with four pre-recorded voice phrases, a standard bell tone, and configurable combinations of voice and tone for distinct alert and evacuation phases.

Key Features & Benefits

• Red-bodied, standard-power loop-powered sounder with integrated red VAD.
• The Gent S3-S-VAD-LPR supports up to 200 voice sounders, 100 VADs, and 70 combined sounder/VADs per loop.
• EN54-23-certified VAD with adjustable light coverage matched to sounder output.
• Four standard voice phrases plus bell tone for clear evacuation messaging.
• Configurable voice/tone modes within a single sounder unit.
• Adjustable sounder volume via commissioning tools, control panel, or HandiLink infrared remote.
• Continuous background monitoring of both sounder and VAD circuits for assured performance.
• Low current draw allows more devices to be installed on each loop, optimising system design.

Compliance & Standards

• EN54-3 and EN54-23 certified.
• CE and UKCA marked.
