Gent S4-715 Optical Detector

Gent S4-715 Optical Detector

The Gent S4-715 is a high-performance analogue addressable smoke detector, engineered for seamless integration with the Gent Vigilon range of control panels. Designed as part of the advanced S-Quad family, it utilises dual-angle optical scatter technology to ensure accurate smoke detection while maintaining exceptional immunity to false alarms.
Ideal for a wide range of commercial, residential, and public buildings, the S4-715’s intelligent design combines local sensor processing with control panel algorithms to deliver rapid detection of genuine fires while filtering out common false triggers such as steam or dust.
The S-Quad optical detector can be configured with certified sensitivity settings tailored to specific environments. Time-of-day programming allows for adaptive detection, reducing the chance of nuisance alarms during high-activity periods. The detector also features a built-in short-circuit isolator for loop protection and provides flexible input/output options for system integration.

Key Features & Benefits

• Intelligent optical smoke detection with dual-angle scatter technology.
• Exceptional immunity to false alarms in challenging environments such as kitchens, shower areas, and industrial spaces.
• Programmable sensitivity levels and time-based modes to suit operational needs.
• Integrated short-circuit isolator for enhanced system reliability.
• Configurable input/output for remote indicators or supervisory integration.
• Fully compatible with EN54-23 visual alarm devices (VADs) in the S-Quad range.
• Works with Gent Vigilon analogue addressable fire alarm systems.

Compliance & Standards:

• EN54-7: Smoke Detectors – Point Detectors Using Scattered Light
• EN54-17: Short Circuit Isolators
