Mains Rated Four Channel Interface | Input/Output with Enclosure

Gent S4-34404 – Four-Channel Mains Switching Interface with Enclosure

The Gent Vigilon S4-34404 is a four-channel mains switching interface designed for seamless integration with Gent Vigilon fire detection systems. Built to handle heavy-duty relay switching for both 24V and 230V applications, it is ideal for controlling damper units, plant equipment, and other building management systems that require high-contact ratings for mains shutdown.

Each channel features a 13A contact rating, making it suitable for demanding applications where high electrical loads must be reliably switched during fire or fault conditions. This interface is supplied with its own protective enclosure, ensuring ease of installation and compliance with site safety requirements.

The S4-34404 expands the Vigilon interface range by offering multiple channels in a single unit, reducing hardware footprint and installation time compared to multiple single-channel devices.

Key Features & Benefits

• Four independent mains switching channels.
• Heavy-duty relay contacts rated at 13A for both 24V and 230V applications.
• Ideal for damper control units and building management system shutdowns.
• Supplied with enclosure for fast, compliant installation.
• Low-voltage control for safe integration with fire alarm systems.
• Expands the Vigilon interface range with greater channel density.
• Available alongside single-channel versions for smaller-scale applications.

Compliance & Standards

• Fully compatible with Gent Vigilon addressable fire alarm systems and designed for integration into EN54-compliant building safety networks.
