Optical Heat Sensor
£55.35 + VAT
The Gent S4-710 S-Quad Optical Heat Detector is a versatile intelligent analogue addressable detector that combines optical smoke detection with a heat-sensing element for rapid, accurate fire detection. Using patented dual-angle optical scatter technology, it provides exceptional immunity to false alarms from steam or dust. It’s fully compatible with the Gent Vigilon range of control panels.
Gent S4-710 S-Quad Optical Heat Detector
The Gent S4-710 is an intelligent analogue addressable detector designed for use with the Gent Vigilon range of control panels. Combining optical smoke detection with a heat sensing element, this versatile unit delivers rapid fire detection while maintaining exceptional immunity to false alarms.
Part of Gent’s advanced S-Quad range, the S4-710 uses patented dual-angle optical scatter technology to accurately detect smoke particles while filtering out potential false triggers from steam, dust, or other airborne contaminants. This makes it ideal for environments such as hotels, leisure facilities, commercial buildings, and mixed-use developments where environmental conditions can vary.
Detection performance is enhanced by local processing within the sensor, which works in tandem with the control panel to ensure fast, accurate fire identification. The S4-710 can also be programmed with multiple sensitivity settings, including time-of-day adjustments, allowing tailored protection for different operational periods.
A built-in short-circuit isolator increases loop resilience, while the flexible input/output options enable integration with remote indicators or supervisory equipment. The unit is compatible with the Gent S4-700 mounting base, ensuring quick installation and reliable system connectivity.
Key Features & Benefits
- Combines optical smoke and heat detection for comprehensive fire sensing.
- Patented dual-angle optical scatter technology improves smoke detection accuracy and reduces false alarms from steam or dust.
- Programmable sensitivity levels for different environments or time periods.
- Built-in short-circuit isolator for improved loop integrity.
- Input/output configurations support remote indicators or supervisory inputs.
- Fully compatible with S-Quad EN54-23 Visual Alarm Devices (VADs).
Works seamlessly with Gent Vigilon analogue addressable control panels.
Compliance & Standards:
- EN54-5: Heat Detectors
- EN54-7: Smoke Detectors – Point Detectors Using Scattered Light
- EN54-17: Short Circuit Isolators
