Gent COMPACT-PLUS Vigilon Compact Plus 1-2 Loop Control Panel with 1 Loop Card
£1,255.50 + VAT
The Vigilon Plus Fire Alarm Control Panel (COMPACT-PLUS) provides powerful, flexible fire detection. Supporting up to 200 loop devices, this EN54-certified system is easy to operate with a clear LCD display. PC-based tools allow for custom fire plans, and the panels are compatible with Honeywell Gent S-Quad multi-sensors, offering a streamlined fire safety solution.
Honeywell Gent Vigilon Plus Control Panels – Compact Plus & Repeat Models
The Vigilon Plus series provides powerful and flexible fire detection control, supporting up to 200 loop devices, including advanced fire sensors, interfaces, manual call points, alarm sounders, and EN54-23 visual alarms.
The Compact Plus 2-loop panels are equipped with an integral EN54-4 compliant power supply and a 24-hour battery standby capacity. A large, backlit 8-line by 40-character LCD display clearly shows fire and fault locations, while the intuitive push-button keypad ensures straightforward operation in an emergency.
With PC-based commissioning tools, fire plans can be customised to match exact site requirements. Network areas can be configured for evacuation or alert, with options for pre-set delays. Fully compatible with the Honeywell Gent S-Quad multi-sensor range, which integrates speech, sounder, and visual alarms in one intelligent device, Vigilon Plus delivers a streamlined solution for comprehensive fire safety.
The Vigilon Plus Repeat Panel offers full display and control functions via connection to the detection loop. Supplied with its own 72-hour power supply, it provides a cost-effective and low-cabling solution for extending control to multiple locations. (Batteries not included — requires 2 × 4015-514-YFR Powersonic Flame Retardant 12V 12Ah units to meet compliance.)
Key Features & Benefits
- EN54-4 PSU & 24-hour standby (Compact Plus).
- Advanced sensing and software processing for rapid, reliable fire detection.
- PC-based commissioning for tailored fire plans.
- High-performance loop card technology with system diagnostics.
- Extended event log stored via flash memory.
- Clear LCD user interface with precise fire/fault location.
- Seamless multi-panel networking for flexible system design.
- Programmable at panel level for on-site configuration.
- All devices connect to a single two-core loop — no separate sounder/repeater wiring required.
- Detailed event history via analogue addressable technology.
- Optional PC-based GUI for centralised monitoring and control.
Certifications
- EN 54-2:1997 + A1:2006
- EN 54-4:1997 + A1:2002 + A2:2006
